MYC-C335X-V4 - Image 3
MYIR | System-On-Modules (SOMs)

MYC-C335X-V4

Precision You Can Trust
NABL-Accredited Calibration | Available on Request

The MYC-C335X-V4 is a highly integrated, low-cost System-on-Module (SoM) based on the TI Sitara AM335x processor, featuring ARM Cortex-A8 cores running up to 1GHz, with PowerVR SGX530 graphics for 2D/3D acceleration. It integrates 512MB DDR3, 512MB NAND Flash, and Gigabit Ethernet PHY. It supports industrial-grade temperatures from -40°C to +85°C, making it suitable for applications like industrial control, automotive systems, and automation..

Request Purchase
  • Detail
  • Special Features
  • Specification

The MYC-C335X-V4 module is designed for high-performance, low-cost embedded applications, integrating a TI AM335x processor with a powerful ARM Cortex-A8 core. It is ideal for industrial environments, with robust features such as graphics acceleration, real-time protocol support (e.g., EtherCAT, EtherNet/IP), and connectivity options like dual Gigabit Ethernet, USB, CAN, and serial ports. This module supports a variety of industrial protocols and applications in automotive, smart home, and automation industries. The module is fully compatible with MYIR’s baseboards and is backed by Linux software resources for quick and efficient development.

  • Processor:

    • TI Sitara AM335x Processor (Cortex-A8, up to 1GHz)

    • Integrated PowerVR SGX530 for 2D and 3D graphics

    • Supports NEON SIMD coprocessor and real-time unit subsystem

  • Memory:

    • 512MB DDR3 SDRAM

    • 512MB NAND Flash

  • Connectivity:

    • On-board Gigabit Ethernet PHY

    • Dual USB2.0 OTG ports

    • 6 Serial ports

    • CAN, RS485, SPI, I2C, PWM

  • Expansion:

    • Two 2.0mm pitch 60-pin expansion connectors

    • 26-pin and 10-pin additional expansion interfaces

  • Operating Temperature:

    • Extended temperature range: -40°C to +85°C

  • OS Support:

    • Linux 4.1.18

  • Processor:

    • TI AM335x Processor (Cortex-A8, up to 1GHz)

    • PowerVR SGX530 GPU

    • Real-time Unit Subsystem (PRU/ICSS)

  • Memory:

    • 512MB DDR3 SDRAM

    • 512MB NAND Flash

  • Connectivity:

    • Gigabit Ethernet PHY

    • 2 x USB 2.0 OTG ports

    • 6 x Serial ports

    • 2 x I2C, 1 x SPI

    • 7 x ADC, 2 x PWM

  • Expansion:

    • 60-pin 2.0mm pitch expansion connectors

    • 26-pin, 10-pin expansion interfaces

  • Temperature:

    • Operating range: -40°C to +85°C

  • OS Support:

    • Linux 4.1.18
